Gravity: IO-laajennussuoja Bluno Beetlelle – Arduino-yhteensopiva

The Bluno Beetle Shield is a compact and convenient expansion board designed specifically for the Beetle BLE (Bluno Beetle). This Bluno Beetle Shield expansion board transforms Beetle’s basic I/O interface into Gravity-compatible 3-pin connectors (signal, VCC, GND), making it much easier to connect DFRobot’s Gravity sensors and modules to your Beetle BLE project.

This shield provides more stable power and ground pins, and includes a switchable external power supply (5–8V), allowing for easier powering and control of the expansion board. Simply solder the Beetle BLE board onto the shield, and this Bluno Beetle Shield is ready to use with all Gravity-compatible modules.

Ominaisuudet

• Expands Beetle’s I/O pins to Gravity 3-pin format with the Bluno Beetle Shield

• Provides more power & ground terminals for external Beetle BLE modules

• Includes a 5–8V power supply input and power switch on the shield

• Ensures easy Gravity-compatible module attachment, no jumper mess

• Perfect match for wearable, prototyping, and low-space Arduino BLE applications

• Compact, stackable expansion board design for embedded setups

Miten se toimii

1. Align the Beetle BLE board over the Bluno Beetle Shield’s I/O pin headers

2. Solder Beetle BLE in place for a secure physical and electrical expansion board connection

3. Kytke Gravity-yhteensopivat anturit/moduulit suoraan Bluno Beetle Shieldin 3-napaisiin portteihin

4. Käytä virtakytkintä ohjaamaan ulkoista 5–8V tuloa Arduino BLE -projektiisi

Ihanteellinen

• Prototyyppien tekeminen Gravity-antureilla ja Bluno Beetle Shieldillä

• Pukeutuva teknologia Beetle BLE:n avulla

• Matala-profiiliset Arduino BLE -sovellukset tällä laajennuskortilla

• Aloittelijaystävälliset asennukset minimaalisella johdotuksella Bluno Beetle Shieldillä

Mitä pakkauksessa on

• Gravity: Bluno Beetle Shield ×1

Yhteensopivuus

• Toimii yhdessä Beetle BLE (Bluno Beetle) laajennuskortin kanssa

• Tukee kaikkia DFRobot Gravity 3-napaisia moduuleja (anturit, toimilaitteet, näytöt)
